Dryden Aqua Air Diffuser – 1m Length (3m³/h, 3/8" Connection)

The Dryden Aqua 1m Air Diffuser is a high-performance aeration system designed for oxygenation and mixing in wastewater treatment, aquaculture, and large water bodies. With fine bubble technology, this diffuser maximises oxygen transfer efficiency, delivering five times the performance of conventional aerators.

Its self-ballasted design eliminates the need for additional anchors, making installation quick and hassle-free.

Key Features:

✔ Fine Bubble Aeration – Enhances oxygen transfer & water circulation.
✔ 1m Length – Ideal for medium-to-large aeration projects.
✔ 3m³/h Air Flow Rate – Ensures effective aeration & oxygen diffusion.
✔ 3/8” Connection – Standard hose tail connection for easy setup.
✔ Self-Ballasted Design – No anchoring required, stays at the bottom naturally.
✔ Highly Durable & Corrosion-Resistant – Long-lasting material resists biofouling & scaling.
✔ Low Pressure Drop (<3 psi) – Maximises energy efficiency & aeration performance.
✔ Quick Maintenance – Easy to clean and service without removing the unit.

Technical Specifications:

• Length: 1m
• Air Flow Rate: 3m³/h
• Connection Type: 3/8” Hose Tail
• Weight: 1.5kg
• Bubble Size: ~1mm (Fine Bubble Diffusion)
• Pressure Drop: Less than 3 psi
• Oxygen Transfer Efficiency: Up to 5kg O₂/kWh

Applications:

✔ Wastewater Treatment Plants – Supports biological treatment & aeration systems.
✔ Aquaculture & Fish Farms – Maintains ideal oxygen levels for aquatic life.
✔ Lakes, Ponds & Reservoirs – Prevents stagnation and enhances circulation.
✔ Industrial Water Treatment – Improves aeration & chemical oxidation processes.
✔ Agricultural Wastewater Management – Boosts aeration efficiency & organic breakdown.

Why Choose the Dryden Aqua 1m Air Diffuser?

Engineered for superior oxygenation and aeration efficiency, the 1m air diffuser provides energy-saving, high-performance aeration for a wide range of water treatment applications.

Important Note:

Product images are for reference only and may not always reflect exact scale or size.
